Anchor by Panasonic UNO 63 Amp Triple Pole C Curve MCB | ISI Marked Double Pole 63A Miniature Circuit Breaker (98032)
Product Details
- Certificates: UNO MCB is ISI marked as per IS/IEC 60898-1:2002. The third party tests are done at CPRI, ERDA. A design registration patent is also registered.
- IP 20 Degree Protection: Finger proof terminals eliminate chances of accidental contact with live parts. All the live parts are shrouded/ inaccessible; ensuring safety of installers.
- Positive Contact Indication: UNO MCB has a clearly visible contact position indicator to identify the real positions of contacts inside the MCB.
- Large Termination Size and Dual Termination: UNO MCB has a high terminal capacity of 35 sq.mm that allows using Aluminium conductors or bus- bars for connection & Bi- Connect termination that allows connection of either cable or bus - bar for better flexibility.
- Breaking Capacity 10kA: The Breaker can break high Short Circuit fault under the conditions of 3 phase fault or phase - Neutral fault, voltage dip. The UNO MCB can protect equipment by opening the contacts even if the high current of 10kA appears.
| Brand | ANCHOR |
| Current Rating | 63 Amps |
| Circuit Breaker Type | Standard |
| Mounting Type | Wall Mount |
| Number Of Poles | 3 |
